Vacuum Operated Floor Mounting Chlorinator

WBacked by diligent professionals, we have been able to proffer our clients superior quality Vacuum Operated Floor Mounting Chlorinator. These products are manufactured by making optimum use of high-grade basic material, procured from the most reliable vendors of the markets industry. Designed to perfection, these products are in compliance with the defined parameters of the industry.

Vacuum Type Floor Cabinet Mounted Chlorinator

Owing to the dexterous professionals, we have been able to provide the customers with a high performing range of Vacuum Type Floor Cabinet Mounted Chlorinator. Our range is developed in strict accordance with the global quality standards by using superior-grade components, which are sourced form the reputed vendors of the market. Further, the range is thoroughly tested on varied parameters to assure flawlessness & zero-defect.

Features:
• Compact structure
• Low maintenance
• High efficiency
• Excellent performance

Vacuum Operated Floor Mounting Chlorinators

Backed by rich industrial experience, we have been able to come up with supreme quality Vacuum Operated Floor Mounting Chlorinators. These products are developed by making use high-grade basic material such as UHM, Teflon, silver, borosilicate glass, Monel, Hastelloy, SS 316L, brass and PVC. Designed to impeccability, these products comply with the defined parameters of the industry. These products are mainly used to flush chlorine with the help of vacuum feed. The vacuum is created by ejector and passes through control valve, flow meter and vacuum regulator. In the vacuum regulator, vacuum moves the provided diaphragm which further removes inlet valve thereby minimizing chlorine gas from supply pressure. Consequently, the chlorine gas passes by flow meter, manual rate valve into differential, pressure regulator. The gas flows to the ejector where the chlorine mixes with water to form chlorine solution from the regulator which is carried by the distribution system to the point of application.

Features:
• It automatically shuts off when water supply fails to eject or if there is break in vacuum line
• In this product the vacuum operations are safely used, as the chlorine pressure is present at only one point
• No mechanical knowledge and training is required to operate this product
• Provided with chlorine and water gauges that indicate chlorine/water pressure of toner and motive water line (only in floor mounting & wall mounting/pedestal mounting      chlorinators
• The flow meter can be changed in accordance with the different capacity
• Provided with vacuum spring, automatic shut-off valve, vacuum controller
• The failure of valve can lead mishandling ventilation of gas into atmosphere

Construction :
Design :
• Vacuum regulator mounted on valve (IS3224) above the liquid trap cum filter to separate foreign materials and liquid trap can be mounted on wall or CS chlorine header     line
• Chlorine pressure gauge present for displaying cylinder/ tonner chlorine pressure is situated on gas filter body/ CS chlorine header line and is connected by strong PVC     pipe to the chlorinator panel
• Water gauge and Vacuum gauge on front panel to display vacuum created in injector and power water pressure
• Differential regulator to absorb vacuum variation and constant vacuum passing to Chlorine flow meter is present between injector and control valve
