Conveyors

» Belt Conveyors

Belt conveyors are the most conventional conveyor system known to human. They are used in transporting heavy to light materials because of its some inherent advantages like safety, economy, versatility, reliability and infinite capacity. Belt conveyors are not only used in transporting raw materials in a production line but they are also used in other industrial applications like packaging, storage and other processing functions. Even ecologically, belt conveyors have proven themselves to be environment friendly when compared to other modes of transport like vehicles running on fuel.

We offer our clients a wide range of premium quality belt conveyors that is used in various industries. The raw material used in fabrication of our belt conveyors is of fine grade and procured from reputed vendors.

Our range is available in following specifications:
Capacity : 1ton/hr to 500 tons/hr
Lengths : 1 meter to 250 meters
Types : Inclined, Horizontal, Shuttle, Tripper, Weighing, Timing, bulk feeding, Sorting
Special : Food grade betting for food processing industries, clitted belts for extra steep applications

» Bucket Elevators

We manufacture wide range of belt bucket elevators for vertical lift of loose materials. These can handle practically all types of gravel materials and can lift it vertically upwards. We offer these for grains, plastic granules, coal, detergents or for similar applications.

Our range includes following.

Types : Positive discharge, Centrifugal discharge and high speed elevators.
Capacity available : 1 ton / hr to 150 tons / hr.
Heights : 3 meter to 50 meters.

» Screw Conveyors

We manufacture and export quality screw conveyors, which are used as bulk material handling device.

Our wide range includes well-designed and finely constructed screw conveyor that is available in following specifications:

Capacity : 100kk/hr to 100 tons/hr
Lengths : 300mm to 30 metre
Size : Dia 4” to 24”
Types : Horizontal, inclined, vertical etc
MOC : MS, SS, Hard faced, mixing, circular troughs, or any other type the customer demands.

» Idlers and Rollers

We supply and manufacture variety of idlers and rollers for belt conveyors. These can be supplied from 300 mm to 1500 mm belt width and diameters ranging from 48 mm to 165 mm. We manufacture them as per IS standards and are fit to perform for 5000 working hours. Bearings we use are of high quality and special bearings can be made available as per specific requirements. We also offer HDPE and LDPE rollers for non-sticky application.

» Side Wall Conveyors

Side Wall Conveyors are very conveniently used, when bulk quantity of material to be handled and if they are to be elevated in bulk quantity at steeper angles. These can handle virtually any material, i.e. high or low in density, abrasive or non-abrasive, even or un-even particle size or any thing.

We offer Apron conveyors from 300 mm width to 1200 mm width. The base can be either conveyor belt or steel slats. We offer all kinds of arrangements that falls in to your requirement. The capacity may be 1 TPH to 500 TPH.

» Vehicle Loaders

We manufacture and supply best quality vehicle loaders and stackers for loading and unloading of vehicles or stacking of bags and cartoons in the industry. These are supplied with either with fix booms, or hydraulically adjusted booms. In hydraulically adjusted booms, the available minimum and maximum heights are 1.5 mtrs to 3.0 mtrs. Available belt widths are 400 mm to 900 mm, depending upon the application. These can handly up to 600 bags per hr.

» Roller Conveyors

We manufacture practically all types of roller conveyors required for different applications.

We offer following types –

Gravity roller conveyors.
Power driven roller conveyors,
Manually operated roller conveyors.
I can supply them in any MOC and for any width ( Roller length ).

» Drag Chain Conveyors

We manufacture all types of drag chain conveyors for handling of materials.

We supply following types of them
Plain conveyors with radler chains – for Oil Industry.
Plain radler chain conveyors – for Dry ash handling.

» Feeding Cum Return Chain Conveyors

We manufacture best quality return bagasse carriers / feeding cum return chain conveyors for handling loose and fluffy materials which are difficult to handle on belt conveyors or on any type of conveyor. We offer these conveyors for bagasse, Ground nut shells, bio mass fuels, wood chips, coffee beans or any such materials.
