Features --
- Suitable for HM, PP, LDPE, HDPE, HMHDPE, LLDPE & other plastic films
- Specialised for Printed Bags
- Two Imported Servo / Stepper Drive and Motor controlled Bag material drawing system which makes the machine Automatic
- Two Separate Imported Photo Sensors for two film of Printed Bags
- Bags with Two different Lengths, Two different Widths, Two different Sizes, Two different Prints & Two different Thicknesses can be used at the same time
- For producing your required bags, just to key-in your required bags length to 'Controller (motion control system)', the machine will be able to make your required bags length automatically without any manual adjustment
- Variable Speed Drive with Infra-Red Sensor for Unwinder system assuring Automatic Feeding of Bag material to machine
- Variable Speed Drive for Main motor drive for changing speed of the machine like fan regulator
- Auto Stopping of the Heater/ Sealer at the top position to avoid tearing of bags
- Automatic Belt Conveyor can also be attached for automatic stacking and collection of bags. (See Accessories)
- Digital Counter with batch preset, alarm and totalizer (See Accessories)
- High production efficiency to save manpower and time
- ‘A Series’ Models has Servo System as Motion Control System which uses Japan make Servo Motor with Servo Drive and Servo Motion Controller
- ‘B Series’ Models has Stepper System as Motion Control System which uses Japan make Stepper Motor with Stepper Drive and Stepper Motion Controller
| Model (A Series) |
DP 0127 A Series |
DP 0232 A Series |
Model (B Series) |
DP 0127 B Series |
DP 0232 B Series |
|---|---|---|---|---|---|
| Working Width | 2” to 10” | 2” to 12” | Working Width | 2” to 10” | 2” to 12” |
| Length Control | 2” to 60” | 2” to 60” | Length Control | 2” to 60” | 2” to 60” |
| The production is doubled as the number of Plastic Rolls are doubled for the Double Decker machine | The productions is doubled as the number of Plastic Rolls are doubled for the Double Decker Machine | ||||
| Bags Production | 60 – 240 bags / min |
60 – 200 bags / min |
Bags Production | 60 – 200 bags / min |
60 – 180 bags / min |
| Power Required | 6 KW | 6.75 KW | Power Required | 6 KW | 6.75 KW |
The product can be customised according to the customer's requirements for the given attachments and size.
