Description : The type RC3 is a stainless steel self centering rocker column load cell with complete hermetic sealing. It is a perfect fit for use in harsh industrial environments.
| Performance Specification | |
| Standard Capacities (Tf.) | 10, 20,30,40,50,60,75,100 |
| Excitation Voltage | 15 VDC - Maximum 20 VDC |
| Nominal Output | 2.0 mV/V |
| Non - Linearity | < ± 0.025 % FSO (Full Scale Output) |
| Hysteresis | < ± 0.05 % FSO |
| Non-Repeatability | < ± 0.02 % FSO |
| Creep (30 minutes) | < ± 0.03 % FSO |
| Zero Balance | ± 1.0 % FSO |
| Input Resistance | 770 ± 5.0 Ohms |
| Output Resistance | 700 ± 3.0 Ohms |
| Insulation Resistance (50VDC) | > 1000 Mega Ohms at 50 VCD |
| Cable | 4 Core Screen Cable 20 Mtrs. |
| Safe Overload | 150% |
| Ultimate Overload | 300% |
| Temp. Compensated Range | 0-60 0C |
| Deflection | < 0.4 mm at rated load |
| Finish & Construction | Stainless Steel - 17-4 PH Outer Casing - SS 304 |
| Environmental Protection Class | IP68 |
| Transient Voltage Protection | Provided |
Type |
B |
R |
d |
D |
H |
10,15,20,30,40 |
150 |
150 |
44 |
90 |
75 |
45,50,60 |
175 |
150 |
44 |
90 |
75 |
75,100 |
200 |
300 |
65 |
90 |
100 |
