Conventional Distribution Transformer
Jain Electricals 3-Phase Distribution Transformers utilize the most advanced and versatile design, delivering excellent performance characteristics. In addition to the precise design the distribution transformers are type test certified at the national laboratories i.e. ERDA/CPRI & MSEDCL Approved.
Technical Specification:
- Ratings:CRGO – 63 to 5000 kVA
- Lamination blade thickness:0.27 mm
- Applicable Standards :IS, IEC, ANSI, JIS, BS etc.
- Cooling :ONAN
- Frequency:50 Hz, 60 Hz
- Polarity :As specified
- Primary voltage : 11/22/33 KV
- Secondary Voltage :415, 433 V (Other Voltages as required)
- Winding material :Copper / Aluminum
- Tapping range : ± 5% in steps of 2.5% (Other tapings as required)
- Impedance :As per standards.
Standard Fittings:
- Pole Mounting Brackets/Tank Base Channels
- Lifting Lugs
- Tank grounding Provision
- Rating and Diagram Plate
- Primary Bushings
- Secondary Bushings
- Conservator
- Breather (Clear view type)
- Oil Filling Hole with caps
- Thermometer Pocket
- Oil Level Indicator
Optional Fittings
- Lightening Arrester
- Conservator
- HV/LV cable box, Bus Duct
- Oil Temperature Indicator
- Buchholz Relay (for ratings above 1000 KVA)
- Pressure Relief Device / Explosion Vent
- Terminal Connectors
- Tap Changer
- Arcing Horns
- Cable Terminations
