We are a renowned manufacturer, supplier and exporter of broad range of four wheel inverted floor conveyor, these are easy to handle and operate at economical cost. These have track aside of conveyor for trolley movement. These conveyors can carry loads up 50 Kg with single point hooking & 100 Kg max. with the help of load bar. Following are its various specifications :
Chain : The chain is available in 6", 8", 10"& 12" pitch and steel wheels dia.
47mm x 14mm thk - 4nos assembled at each chain pitch. These chain is made of 32mm x 4mm thk En 8 links and En 8 axles of dia.1/2". The chain pitch avail is double then minimum components.
Drive Unit : Caterpillar is available that can be used as the design requirement.
Multi drive units with speed synchronization can use longer conveyor loops.
Tracks and Turns: These are made using formed angels 38 x 38 x 3 with Thk and Track brackets at every 625mm. These are available in suitable radius.
