Cryostat
As per the FDA rules & guidelines the plasma either Deep Frozen or at —30°C is required to thaw at +4°C as quick as possible. The process is essential to improve the yield over the conventional method of conduction & convection of air.
Main Features
The cryo precipitate bath in the extension of extensive range of Polfrost
cryostats which has almost 28 models
ranging from 5 litres to 50 litres of
volume & temperature range of +200°C to —80°C. (Details available on
request)
Construction
Inside a stainless steel chamber with refrigeration & counter flow heating
of hot gas in the chamber equipped with
solenoids for cooling & heating to
control the temperature of the bath precisely at +4°C; outside CRC
Powder coated
body & the whole unit mounted on castor wheels for easy
movement as the user-friendly features; a strong circulating 0
pump/agitator for even distribution of temperature & fast removal of heat
from plasma.
Special Features
- 5/10/15 Plasma Bags Holder.
- PID controller with PT-100 Sensor.
- Strong circulating & agitation.
- Safe and reliable cooling process.
- Cooling & heating with precise temperature control.
- Drain-port for bath liquid.
Specifications
Model
:
CRYOBATH PT - 045
Temperature range
:
+4°C
Temperature accuracy
:
±1°C
Bath capacity
:
22L
Bath opening
:
400 x 250 mm
Refrigeration
:
CFC free hermetically sealed system
Condenser
:
Air-Cooled
Cooling capacity
:
at +4°C 1250W
Dimension
:
965 x 660 x 620 mm
Power
:
230V, 1 phase, 50 cycle
Range
Units shall be supplied as per customer requirements and specifications.
