Plant - II PCB Manufacturing

PCB Plant Facilities
• GIGA 8888 (8 Spindle CNC machine) 1 no
• POSALUX CNC ( 5 & 6 spindles) 2 nos
• CNC 1 Spindle ( BUNGARD )
• CNC 1 Spindle 2 Nos. ( German Make)
• V grooving machine with pin setting
• Circular saw cutting machine with registration
• Screen exposure Machine
• Hot Roll dry film laminator with static eliminator, Fume extraction blower & table double side
• Conveyorised double side scrubbing / deburring machine with oscillation
• Double side exposure machine 5KW.
• Double side exposure machine 8KW.
• Conveyorised double side developing machine with oscillation
• Auto screen printing machine 2 Nos.
• Conveyorised double side PISM developing machine with oscillation
• Conveyorised double side Etching machine with oscillation
• Screen washing booth with mid pressure rinse
• Screen drier with two compartment
• Electro less plating line
• Electrolytic Plating Line
• Conveyorised dry film stripping without oscillation
• Conveyorised double sided tin stripping machine with oscillation
• Conveyorised double sided PRE HAL
• HAL Machine (GYREX)
• HAL Machine (EPS)
• Conveyorised double sided Post HAL
• Final cleaning machine
• WABASH Multilayer press
• Universal bare board tester (BBT)
• Flying probe tester (MANIA)
• MANIA TOWER BBT Machine
• Power Shearing Machine
• Mechanical Shearing Machine 4 Nos
• UV Curing Machine (HANSA)
• Ovens (Digital Temperature Control) 2 Nos
• Magnifying Lens 200X 2 Nos
• Magnifying Lens 20X 10 Nos
• Digital Copper Thickness Tester
• Power alternate solution :- 125KVA DG Set

Type of PCB’s
• Single Side Conventional
• Double Side PTH
• Multilayer upto 6 Layers
• Metal Clad PCBs

Type Of PCB’s Materials
• CEM1
• CEM3
• FR2
• FR4
• Polyimide
• RT Duroid
• Poly Tetra Fluro Ethylene
• Aluminium Base
