| Engine |
| Type |
Ashok Leyland 400 |
Ashok Leyland 400 |
| Power |
105 BHP |
105 BHP |
| R.P.M. |
2200 |
2200 |
| Model |
H6 (H-series, 6 cylinder engine) |
H6 (H-series, 6 cylinder engine) |
| Bore(mm) |
104 |
104 |
| Stroke(mm) |
113 |
113 |
| Compression ratio |
17.5:1 |
17.5:1 |
| FIP |
Inline |
Inline |
| Max Power, KW @ Speed |
74.3KW(101 HP) @ 2200 |
74.3KW(101 HP) @ 2200 |
| Min Idle |
600 RPM |
600 RPM |
| Emisssion norms |
BS-III, CEV |
BS-III, CEV |
| Operating cylinder pressure, bar |
120 |
120 |
| Maximum injecion pressure, bar |
750 |
750 |
| Altitude Capacity, m |
1500 |
1500 |
| Starting System |
| Motor |
Lucas TVS 24V Starter Motor |
Lucas TVS 24V Starter Motor |
| Alternator |
Lucas |
Lucas |
| Cooling System |
| Radiator |
950*740(M.M.) |
950*740(M.M.) |
| Bar Radiator Capacity |
20.2 |
20.2 |
| Assembling System |
| Threshing Drum |
|
|
| Width |
1258 M.M. |
1133 M.M. |
| Outside dia(M.M.( |
600 |
600 |
| Starw Walkers |
| Number |
6 |
5 |
| Type |
Closed Rack Type Serrated size edges with 5 steps on each straw walker |
Closed Rack Type Serrated size edges with 5 steps on each straw walker |
| Length |
3850 |
3850 |
| Width |
240 |
206 |
| Cleaning Sieves |
| No of Sieves |
2 |
2 |
| Types |
Open Lip Frog Mouth |
Open Lip Frog Mouth |
| Over all Siize of Sieves |
|
|
| Length M.M. |
Front-1240 , Rear-630 |
Front-1240 , Rear-630 |
| Width M.M. |
Front- 1215 ,Rear - 1214 |
Front- 1090 ,Rear - 1089 |
| Bottom Sieve |
|
|
| Length |
1240 |
1240 |
| Width |
1215 |
1092 |
| Capacity |
| Grain Tank |
1735Kg. Wheat |
1535Kg. Wheat |
| Hydraulic Tank |
16 Ltr. |
16 Ltr. |
| Fuel tank |
323.5 ltr. |
323.5 ltr. |
| Tyres |
| Front |
(18.4/15-30) 14 PR |
(18.4/15-30) 14 PR |
| Rear |
(7-50-16) 12PR |
(7-50-16) 12PR |
| Range of Speed |
| Minimum |
522 |
522 |
| Maximum |
988 |
988 |
| Output |
|
|
| Wheat |
2.5 to 4 Acres per Hour |
2.5 to 4 Acres per Hour |
| Paddy |
2 to 3 Acres Per Hour |
2 to 3 Acres Per Hour |
| Cutting Bar Size |
| Working width with shoes (mm) |
4400 |
4100 |
| Effective cuuter bar width(mm) |
4280 |
3980 |
| No. of spacing of knife guards |
56(28 pairs) 54 (26 pairs) |
|
| No & types of knife blades |
57 seerated 57 serrated |
|
| Dimensions(mm) |
|
|
| Length |
Working - 8405, Transport - 11920 |
Working - 8405, Transport - 11620 |
| Width |
Working - 4690 , Transport - 2880 |
Working- 4390, Transport - 2775 |
