Infrastructure

Machines

Sr No.	Details	Make	Specification			Quantity
1	VMC Double Column	MANFORD DL 3224N	3200	2400	1200	1 Nos.
2	VMC Double Column	MANFORD DL 3224N	3500	2500	1200	1 Nos.
3	VMC	HCMC 2082 Hardford	2100	1000	850	1 Nos.
4	VMC	Hardford Omnis	1270	610	610	1 Nos.
5	VMC	BFW Chakra	1020	610	610	1 Nos.
6	VMC	PINNACLE QV147	1500	750	700	1 Nos.
7	VMC	MANFORD VL 1600	1600	750	750	1 Nos.
8	VMC	MANFORD VL 1300	1300	750	750	1 Nos.
9	VMC	HEXA Router	3000	3000	1150	1 Nos.
10	CNC EDM	-	775	450	320	2 Nos.
11	CNC EDM	-	-	-	-	5 Nos.
Quality Machining supplier for machining support						15.

Capability Center – CAD & CAM

Sr No.	Details	CAD / CAM	No. Of Seats
1	PRO. Engg. WILD FIRE – 5	3D CAD	1
2	Unigraphics UG	3D CAD	4
3	Auto CAD R-2014	2D CAD	2
4	Work NC	CAM	2

VMC-01 DL 3224N MANFORD Vertical Machining Center.

Table Size	3000 X 2000
Travel Ranges	3200 X 2400 X 1200 (X x Y x Z mm)
Spindle Speed	6000 rpm

VMC -04 Omnis Hardford Vertical Machining Center

Table Size	1350 X 650 X 650
Travel Ranges	1270 X 610 X 610 (X x Y x Z mm).
Spindle Speed	8000 rpm

VMC-02 DL 3224N MANFORD Vertical Machining Center

Table Size	3500 X 2500
Travel Ranges	3500 X 2500 X 1200 (X x Y x Z mm)
Spindle Speed	8000 rpm

VMC -07 MANFORD Vertical Machining Center. ( VL 1600 )

Table Size	1800 X 750
Travel Ranges	1600 X 750 X 750 (X x Y x Z mm).
Spindle Speed	8000 rpm

VMC -03 HCMC 2082 Hardford Vertical Machining Center

Table Size	2300 X 1000 X 850
Travel Ranges	2100 X 1000 X 850 (X x Y x Z mm).
Spindle Speed	6000 rpm

VMC -08 MANFORD Vertical Machining Center. ( VL 1300 )

Table Size	1500 X 750
Travel Ranges	1300 X 750 X 750 (X x Y x Z mm).
Spindle Speed	8000 rpm

VMC -06 PINNACLE QV147 Vertical Machining Center

Table Size	1650 X 800
Travel Ranges	1500 X 750 X 700 (X x Y x Z mm)
Spindle Speed	8000 rpm

VMF -05 BFW Chakra Vertical Machining Center

Table Size	1150 X 610 X 610
Travel Ranges	1020 X 610 X 610 (X x Y x Z mm)
Spindle Speed	10000 rpm
