International standard manufacturer of Heatless Air Dryer. Our Heatless Air Dryers are the best in quality and are used for instrumentation and process applications as well.
How it works?
Heatless Air Dryer often referred as pressure swing adsorption dryer. The compressed air is passed through a Coalescing type Pre fitter. Here dust particles, water and oil coalesce and removed from the stream. Then the air is passed through a pressure vessel with two "towers" filled with a media such as activated alumina, molecular sieve or other Desiccant material. This desiccant material attracts the water from the compressed air via adsorption. As the water clings to the desiccant, the desiccant "bed" becomes saturated.
The dryer is timed to switch towers based on a standard cycle, once this cycle completes some compressed air from the system is used to "purge". The duty of the desiccant is to bring the pressure dew point of the compressed air to a level in which the water will no longer condense. A standard dew point that is expected by a Heatless Air Dryer is -40°C (-40° F), required dew point is dependent on application and - 70 °C required in some applications.
- CNC machines
- CMM machines
- Spray painting
- Nitrogen generators
- laboratory air & gas applications
- Powder coating etc.
- All alluminum rust-free construction,Compact & Lightweight
- Easy and flexible installation,Simple maintenance
- Outlet air quality according to ISO 8573-1, Table 3, Class 2
Yunik Air Solutions is a well-established company involved in the manufacturing of Compressed Air and Cooling Systems since last few years.We are rigorously involved in the manufacturing of Air Dryers, Air Filters and Valves.
