YUNIK AIR SOLUTIONS

Refrigerated Air Dryers

International standard manufacturer of Refrigerated Compressed Air Dryer. Our Refrigerated Air Dryers are the best in quality and purifies impure compressed air containing dust, oil as well as moisture.

Working Principal
Warm Compressed air enters into the air to air heat exchanger, where it is precooled by outgoing cold refrigeration air. Pre-cooling makes it possible to use a smaller "more economical" refrigeration unit. Then the pre-cooled air enters into the Freon Heat Exchanger, where it is cooled down to +3 degrees celcius. At this cool temperature, moisture condenses into liquid droplets, which are removed from the air stream by a very efficient demister and automatically drained by an Automatic Drain Valve. The cold dry compressed air passes back through the secondary side of the Air to Air Heat Exchanger, where it is re-heated by the incoming warm air. Reheating the outgoing compressed air increases temperature by heat with incoming warm air.

The dry air coming out from the air dryer is ready to use for instrumentation and process air applications.

Range of Products

• YLRD Series
- This is low pressure Air Dryer Series range from 15CFM to 2000 CFM
- Can be used upto a compressed air pressure of 16 bar

• YHRD Series
- This is high pressure Air Dryer Series range from 25CFM to 1500 CFM
- Can be used upto a compressed air pressure of 40 bar

Applications

- CNC machines
- CMM machines
- Spray painting
- Nitrogen generators
- laboratory air & gas applications
- Powder coating etc.

Features

- Compact Design,High Quality Finishing, Easy Installation and Environment Friendly
- Power Saving,Low Pressure Drop,More Reliability
- Reduced Maintenance, Constant dew point at all varying load
