Our Products

LL-LDPEHM-HDPE Blown Film Plant

Model	LH40	LH45	LH55	LH55	LH40
Lay Flat (mm)	50-450	100-600	150-750	150-950	250-1250
Lay Flat (inch)	2-18	4-24	6-30	6-38	10-50
Film Thickness (Micron)	20-75	20-75	20-75	20-75	20-75
Max Output (Kg/hr.)	30	45	50	60	80
Screw Dia (mm)	40	45	50	55	65
L/D	26	26	26	26	26
Gearbox	Helical	Helical	Helical	Helical	Helical
Main Motor	7.5HP(960 RPM)	10HP	12.5HP	15HP	25HP
Heating Zone	2	2	3	3	4
Die Type	Spiral	Spiral	Spiral	Spiral	Spiral
Die (mm)	150	200	250	300	400
Filter	Candle	Candle	Candle	Candle	Candle
Winder	Surface( 2 Station)	Surface( 2 Station)	Surface( 2 Station)	Surface( 2 Station)	Surface( 2 Station)
Connected Load (HP)	20	24	30	35	45
Installation Area (LXWXH) (ft)	16x10x10	16x10x11	17x12x12	17x12x14	17x12x16
Optional	Rotary Die, Auto Hopper Loader, Chiller, Corona Treater, 4 Station Winder
