Micro Fine Pitch Magnetic Chuck
We are one of the most reckoned organizations engaged in offering Magnetic Chucks. In various industrial processes, it is widely used for holding ferro-magnetic work pieces owing to its magnetic properties. These products are appreciated by our clients as they provide optimum performance without any disturbance.
Features :
- Holding device for surface grinding machine, Tool & cutter grinder, Spark erosion machines.
- Fine Pitch (1 + 0.5) makes it suitable to hold very thin & small jobs.
- The working face & bottom face is perfectly parallel.
- Poles individually magnetized for full loading power.
- Suitable to hold thin & small jobs.
- Bottom plate has suitable extension to clamp on table.
- Better magnetic grip due to close pole.
- Easy operated ON-OFF lever
| Sr. No. | Cat No. | Size (mm) | Pole Pitch (mm) |
| 1 | SMP 3001 | 250 L x 150 W x 60 H | 1.5 |
| 2 | SMP 3002 | 300 L x 150 W x 60 H | 1.5 |
| 3 | SMP 3003 | 350 L x 150 W x 60 H | 1.5 |
| 4 | SMP 3004 | 400 L x 150 W x 60 H | 1.5 |
| 5 | SMP 3005 | 450 L x 150 W x 60 H | 1.5 |
