Sine-Table
We are one of the most reckoned organizations engaged in offering Magnetic Chucks. In various industrial processes, it is widely used for holding ferro-magnetic work pieces owing to its magnetic properties. These products are appreciated by our clients as they provide optimum performance without any disturbance.
Features :
- Used for Precision measurement, setting of angles & Light machining.
- Accuracy for Square ness, Flatness & Parallelism within 0.010mm upto 200L & 0.015mm upto 450L.
- Angle can be set within ±5 seconds.
- Centre Distance between roller is within 0.005mm.
- Made from high quality alloy steel
- Hardness - 60 ± 2 Rc & Tempered.
- Magnetic Table for job holding.
- Firm hinged clamp to reduce possibility of distortion.
- Magnetic Chuck with fine Pitch (1.5mm)
| Sr. No. | Cat No. | Size (mm) | Center Distance | Inclination |
| 1. | SMP-15001 | 150 L x 120 W x 65 H | 70 | 0 - 45º |
| 2. | SMP-15002 | 250 L x 150 W x 65 H | 100 | 0 - 45º |
| 3 | SMP-15003 | 300 L x 150 W x 65 H | 100 | 0 - 45º |
| 4. | SMP-15004 | 450 L x 150 W x 65 H | 100 | 0 - 45º |
| 5. | SMP-15005 | 450 L x 150 W x 65 H | 150 | 0 - 45º |
