Press – Overview / Process

A simple frame, fabricated from steel, containing a bottle jack or simple hydraulic cylinder. Good for general-purpose work in the auto mechanic shop, machine shop, garage or basement shops, etc. Typically 1 to 30 tons of pressure, depending on size and expense. Classed with engine hoists and engine in many tool catalogs.

A fluid, such as oil, is displaced when either piston is pushed inward. The small piston, for a given distance of movement, displaces a smaller amount of volume than the large piston, which is proportional to the ratio of areas of the heads of the pistons. Therefore, the small piston must be moved a large distance to get the large piston to move significantly. The distance the large piston will move is the distance that the small piston is moved divided by the ratio of the areas of the heads of the pistons. This is how energy, in the form of work in this case, is conserved and the Law of Conservation of Energy is satisfied. Work is force times distance, and since the force is increased on the larger piston, the distance the force is applied over must be decreased.
