Side Mounted Level Switch

nel> Up To Six SPDT Switches per Unit (NO & NC Contacts)
Interface & Total Level Capability
Total Level Capability
Trip Point Adjustable Without Removing Vessel from Service
316L Stainless Steel Wetted Parts Standard
Field Adjustable and Replaceable Switches
316/316L Standard
Terminal Block(s) Included

Specifications :

• Mechanical: Housing Type Explosion Proof Powder Coated Aluminum Compartment
• Materials of Construction 316L Stainless Steel Standard Sensor 5/8” OD / 16 mm
• Maximum Pressure 800 psig @ 300ºF / 55 bar @ 149ºC Length 8 inches to 20 feet / 0.2 to 6 meters
• Electrical Switch Type Magnetically actuated, hermetically sealed, magnetically biased bistable reed switch, each contact, single pole double throw
• Switch Action Break before make Contact Material Rhodium
• Maximum Dead band Approximately ± 0.75 in/1.9 cm of Float travel Contact Ratings AC rating (max): 250 V or 1 amp resistive or 100 VA DC rating (max): 125 V or 0.5 amp resistive or 100 W Lamp Load Rating: 1/3 A @ 125VAC
• Ambient Operating -58ºF/ -55ºC to 150ºF/ 66ºC Temperature Range
• Minimum Operating -50ºF/ -45ºC
• Maximum Operating 200ºF / 93ºC
