HEATOL 32/100 - HEAT TRANSFER OIL
Heatol 32 is hydrocarbon type heat transfer medium used in Thermic Heaters. They are based on specially selected and highly refined base oils fortified with additives. They have excellent Thermal stability, Oxidation stability and low evaporation at elevated temperature offering good pumpabiliy essential for long life of thermic heating system. Heatol 100 is useful where the Thermic fluid system has to operate continuously at high temperatures 280/300 0C.
| TECHNICAL DATA HEATOL 32 | |||
| Sr No. | Properties | Test Method | Specification |
| 1 | Density at 29.5 0c | ASTM: D 941 | 0.830-.840 |
| 2 | Flash Pt. COC,0 C, Min. | ASTM: D 92 | 220 |
| 3 | Copper Strip Corrosion 3 hrs. @ 100 0 C , Max. | ASTM :D 130 | 1 |
| 4 | Neut. Number mg KOH/gm, Max. | ASTM : D 974 | 0.01 |
| 5 | Pour Pt. 0 C | ASTM: D 97 | -12 |
| 6 | Water Content % | ASTM : D 95 | < 0.1 |
| 7 | Carbon residue (Conradson)% | ASTM : D 189 | 0.02 |
| 8 | Viscosity at 40 0C in CSt. | ASTM : D 445 | 28 to 33 |
| 9 | Viscosity at 100° C in CSt. | ASTM : D 445 | 5 to 7 |
| 10 | Aniline Point °C | ASTM D 611 | 115 |
| 11 | Thermal Expansion lit/0 C | 0.0008 | |
| 12 | Specific Heat Kcal/Kg 0C | ||
| 260 0C | 0.73 | ||
| 280 0C | 0.751 | ||
| 300 0C | 0.772 | ||
| Thermal Conductivity, kcal/hr-mt 0C | |||
| 260 0C | 0.097 | ||
| 280 0C | 0.096 | ||
| 300 0C | 0.095 | ||
