Salient Features
- Easy for Installation with HDPE/UPVC/GI Pipe..
- Tiffin Box Pump Design.
- Copper Rotor Design.
- SS Impeller & SS Bowl in Fabrication design.
- Motor OD for V4: 96 mm.
- 1.5 HP to 5 HP models have 4” Motor.
Applications
- Residential
- Commercial
- Multistorey Buildings
- Agriculture & Irrigation Purpose.
- Drip & Sprinkler Systems.
Technical Specifications Single phase
- Power Rating Range: 1.5 HP to 2 HP
- Head Range in Meters: 30 Meters to 137 Meters
- Discharge Range in LPM: 125 LPM to 20 LPM
- Working Voltage Range: 160 Volts to 240 Volts
- Frequency: 50 Hz
- Type of Duty: S1
Technical Specifications Three phase
- Power Rating Range: 3 HP to 5 HP
- Head Range in Meters: 37 Meters to 200 Meters
- Discharge Range in LPM: 125 LPM to 20 LPM
- Working Voltage Range: 240 Volts to 440 Volts
- Frequency: 50 Hz
- Type of Duty: S1
