Salient Features
- Carbon/ Stainless Steel thrust bearings.
- Stainless steel shaft to prevent rusting.
- Wet type winding with polyester wrapped winding wire & Copper rotor.
- Can withstand voltage fluctuations from 240V to 440V.
- Anti-corrosive paint for external surfaces.
- S1 duty pumps.
- Models with wide range of discharge and head combination.
- Built meticulously for meeting the growing demands of customers.
- Compact in size and easy to install in an open well.
Applications
- Agriculture purpose.
- Public water supplies.
- Industrial uses.
- High rise buildings.
- Construction Site.
Technical Specifications
- Power Rating Range: 5 HP - 25 HP
- Head Range in Meters: 10 Meters - 210 Meters
- Discharge Range in LPM: 1600 LPM - 100 LPM
- Working Voltage Range: 300 Volts - 440 Volts
- Insulation: E Class
- Max Liquid Temp: 35 degree Celsius
Material of Construction
- Impeller: CI FG 200
- Delivery Casing: CI FG 200
- Shaft: AISI-410
- Motor Body: CI FG 200 / Stainless Steel / MS
- Mechanical Seal: C+CER+BUNA N
- Gland Packing: Nylon Asbestos
- Rotor: Aluminum/Copper
