Salient Features
- Used where there is no electricity and power is generated by tractor.
- Stainless Steel ball bearings on both the sides.
- Italian technique is used for designing the pump.
- Available in both 545 RPM as well as 1000 RPM.
- Anti-corrosive paint for external surfaces.
- Direct assembly to the tractor PTO shaft.
- Built meticulously for meeting the growing demands of customers.
- Compact in size and easy to install in an open well.
Applications
- Dewatering purpose.
- Agriculture & Irrigation purpose
Technical Specifications
- Power Rating Range: 15 HP – 30 HP
- Head Range in Meters: 17 Meters – 78 Meters
- Discharge Range in LPM: 2300 LPM – 325 LPM
- Operating Speed : 545 RPM -1000 RPM
- Sealing Arrangement: Gland Packing
- Max Liquid Temp: 35 degree Celsius
- Drive Power Input: Tactor PTO Shaft
Material of Construction
- Impeller: CI FG 200
- Delivery Casing: CI FG 200
- Shaft: MS
- Gland Packing: Nylon Asbestos
- Gearbox: High Carbon Steel Gear
