Salient Features
- Stainless Steel ball bearings on both the sides.
- Ability to withstand high voltage fluctuations from 250V to 440V.
- Single phase 460V & 230 V Monoblock pumps are also available from 0.5 HP to 5 HP.
- Air cooled by using fans.
- Suction capacity 25 ft.
- Anti-corrosive paint for external surfaces.
- S1 duty pumps.
- High efficiency & energy saving design.
- Built meticulously for meeting the growing demands of customers.
- Compact in size for easy to installation
Applications
- Sprinklers & Drip irrigation.
- Commercial Complexes & High-Rise Buildings.
- Agriculture & irrigation Purpose.
Technical Specifications Single Phase
- Power Rating Range: 3 HP to 25 HP
- Head Range in Meters: 12 Meters to 78 Meters
- Discharge Range in LPM: 2550 LPM to 150 LPM
- Working Voltage Range: 250 Volts to 440 Volts
- Operating Speed: 2800 RPM
- Insulation: F Class
- Max Liquid Temp: 35 degree Celsius
- Sealing Arrangement: Gland Packing / Mechanical Seal
Material of Construction
- Impeller: CCI FG 200
- Delivery Casing: CI FG 200
- Shaft: AISI-410
- Motor Body: CI FG 200
- Mechanical Seal: C+CER+BUNA N
- Gland Packing: Nylon Asbestos
- Rotor: Aluminum / Copper
