Salient Features
- Stainless Steel ball bearings on both the sides.
- Ability to withstand high voltage fluctuations from 250V to 440V.
- Pumps up to 2HP are available in single as well as three phase.
- Air cooled by using fans.
- Suction capacity 25 ft.
- Anti-corrosive paint for external surfaces.
- S1 duty pumps.
- Non-overloading power curve within the operating head range.
- Top flat efficiency curve for the entire operating range.
- Built meticulously for meeting the growing demands of customers.
- Compact in size for easy to installation
Applications
- Sprinklers & lift irrigation.
- Village water supply schemes.
- Commercial Complexes
- Apartments & high-rise buildings.
Technical Specifications Single Phase
- Power Rating Range: 1 HP to 30 HP
- Head Range in Meters: 10 Meters to 100 Meters
- Discharge Range in LPM: 1210 LPM to 15 LPM
- Working Voltage Range: 250 Volts to 440 Volts
- Operating Speed: 2800 RPM
- Insulation: F Class
- Max Liquid Temp: 35 degree Celsius
- Sealing Arrangement: Gland Packing / Mechanical Seal
Material of Construction
- Impeller: CCI FG 200
- Delivery Casing: CI FG 200
- Shaft: AISI-410
- Motor Body: CI FG 200
- Mechanical Seal: C+CER+BUNA N
- Gland Packing: Nylon Asbestos
- Rotor: Aluminum / Copper
