We are a customer driven organization offering standard Magnetic Lifting Equipments that are known in the industry for their superior functionality. The entire range is available in customized sizes and can also be custom made as per the specifications provided by our valuable clients.
Permanent Magnetic Lifters
Features :
- Used for lifting & handling of steel plates, heavy block & castings as well as heavy round or cylindrical parts.
- The 1 : 3.5 safety factor of the recommended load to the Test load ensures use at optimal working conditions even with Substantial air gaps & surface conditions.
- Compact design, strong magnetic pull, total work safety.
- Easy operated lever for ON-OFF.
- Spring loaded block at side for safety feature.
- Suitable for Flat & Round jobs.
- No damage on job during operation.
- Lifts upto 50% of the specified capacity of the lifter.
| Sr. No. | Cat No. | Size (mm) | Lifting Capacity for flat job | Tested Capacity for flat job | Weight |
| 0 | SMP 80500 | 90 L X 65 W X 85H | 100 Kg | 350 Kg | 4 Kg |
| 1. | SMP 80501 | 170 L x 85 W x 105 H | 200 Kg | 700 Kg | 9 Kg |
| 2. | SMP 80502 | 170 L x 85 W x 105 H | 250 Kg | 875 Kg | 9 Kg |
| 3. | SMP 80503 | 230 L x 85 W x 105 H | 300 Kg | 1050 Kg | 13 Kg |
| 4. | SMP 80504 | 230 L x 85 W x 105 H | 450 Kg | 1575 Kg | 14 Kg |
| 5. | SMP 80505 | 255 L x 110 W x 130 H | 600 Kg | 2100 Kg | 25 Kg |
| 6. | SMP 80506 | 290 L x 110 W x 130 H | 700 Kg | 2450 Kg | 30 Kg |
| 7. | SMP 80507 | 350 L x 130 W x 135 H | 1000 Kg | 3500 Kg | 45 Kg |
| 8. | SMP 80508 | 405 L x 150 W x 160 H | 1500 Kg | 5250 Kg | 68 Kg |
| 9. | SMP 80509 | 470 L x 170 W x 185 H | 2000 Kg | 7000 kg | 103 Kg |
| 10. | SMP 80510 | 570 L x 300 W x 270 H | 3000 kg | 9000 kg | 280 Kg |
| 11. | SMP 80511 | 730 L x 350 W x 310 H | 5000 kg | 15000 Kg | 540 Kg |
