• Material-independent detection
• Detection possible even through container wall
• Reduced susceptibility to contamination using compensation electrode
• Various housings
• Expanded temperature ranges
• Active area made of PTFE
• No blind region

CFAK 12/18/30
	Characterstics For applications in contaminated, water-based media Level control, in contact with medium Sealed housing Compact and smooth surface Suppression of dirt and cleaning agents	Dimension:M12 x 1 Nominal sensing 0 mm Distance Resolution:< 0,1 mm
switching frequency: < 15 Hz	Output signal:

CFAK 12
	Characterstics Unshielded Fixed sensing distance Sealed housing Level control, in contact with medium Reliable detection via suppression of mist and contamination	Dimension:M12/18 x 1 M30 x 1,5 Nominal sensing 0,5 ... 8 mm Distance Resolution:< 0,1 mm
switching frequency: < 15 Hz	Output signal:

CFAK 18/30
	Characterstics shielded Housing material brass nickel plated Sensitivity adjustment using potentiometer Cable and connector versions	Dimension:M18 x 1 M30 x 1,5 Nominal sensing Distance:4 / 8 mm Resolution:< 0,3 mm
switching frequency: < 50 Hz	Output

CFAM 12 / 18 / 30
	Characterstics Unshielded Sensing distance adjustable Sealed housing Level control, in contact with medium Reliable detection via suppression of mist and contamination	Dimension:M12 x 1 M18 x 1 M30 x 1,5 Nominal sensing Distance:4 / 8 mm Resolution:< 0,3 mm
switching frequency: < 50 H	Output

CFBM 20
	Characterstics shielded Unthreaded metal housing Sensitivity adjustment using potentiometer	Dimension:ø 20 mm M30 x 1,5 Nominal sensing 10mm Distance Resolution:< 0,3 mm
switching frequency: < 50 Hz

CFBM 20
	Characterstics Unshielded Sensitivity adjustment via potentiometer Expanded temperature range -40 °C to +250 °C Anti-stick sensor head made of PTFE and V2A stainless steel Highly resistant to aggressive media	Dimension:M30 x 1,5 Nominal sensing 15mm Distance Resolution:< 0,3 mm
switching frequency: < 50 Hz

CFBM 20
	Characterstics Shielded Sensitivity adjustment using potentiometer Cable and connector versions	Dimension:30 x 65 x 18,5 mm Nominal sensing 15mm Distance Resolution:< 0,3 mm
switching frequency: < 50 Hz
