• Smallest deviations in series production
• Extremely temperature-stable
• High switching frequency
• Enhanced distance
• Miniature sensors
• Several housing lengths per dimension
• Expanded temperature ranges
• Protection class IP 67
• Output PNP/NPN

)

IFRM 03
	Characterstics Robust stainless steel housing Cable connection	Dimension: ø 3 mm Nominal sensing Distance: 0,8 mm
switching frequency: < 3 kHz	Output signal:
Specific Characterstics:	Short sensor head with remote electronics

)

IFRM 04
	Characterstics Robust stainless steel housing With M5 connector High installation torque	Dimension: ø 4 mm / M4 x 0,5 Nominal sensing Distance: 0,8..1mm
switching frequency: < 5 kHz	Output signal:
Specific Characterstics:	NAMUR sensors Short housing with wire output

)

IFRM 05
	Characterstics Robust stainless steel housing With M5 connector High installation torque	Dimension: M5 x 0,5 Nominal Sensing Distance: 1 mm
switching frequency: < 5 kHz	Output signal:
Specific Characterstics:	NAMUR sensors Short housing with wire output

)

IFRM 06
	Characterstics Robust stainless steel housing Short type	Dimension: ø 6,5 mm Nominal Sensing Distance: 1,5..6 mm
switching frequency: < 5 kHz	Output signal:
Specific Characterstics:	High temperature sensors up to +100 °C NAMUR/ATEX sensors GammaProx for large sensing distances

)

IFRM 08
	Characterstics Robust stainless steel housing Short type	Dimension: M8 x 1 Nominal Sensing Distance: 1,5...6 mm
switching frequency: < 5 kHz	Output signal:
Specific Characterstics:	High temperature sensors up to +180 °C NAMUR/ATEX sensors GammaProx for large sensing distances

)

IFRM 12
	Characterstics Metal housing brass nickel plated	Dimension: M12 x 1 Nominal Sensing Distance: 2 ... 10 mm
switching frequency:< 2 kHz	Output signal:
Specific Characterstics:	High temperature sensors up to +180 °C High pressure sensors up to 500 bar Welding and magnetic noise up to 90 mT PBT plastic housing Banking screw of hardened steel NAMUR/ATEX sensors

IFRM 12 IFRM 18
	Characterstics Metal housing brass nickel plated Cable and connector versions Extended working temperature range 40 ... +80 °C	Dimension: M12 x 1 / M18 x 1 Nominal Sensing Distance: 6... 12mm
switching frequency: < 500 Hz / < 1 kHz	Output signal:

IFRM 18
	Characterstics Metal housing brass	Dimension: M18 x 1 Nominal Sensing Distance: 5...20 mm
switching frequency: < 500 Hz	Output signal:
Specific Characterstics:	High temperature sensors up to +180 °C High pressure sensors up to 500 bar Welding and magnetic noise up to 90 mT PBT plastic housing Sensors with two adjustable switching points NAMUR/ATEX sensors

IFRM 30
	Characterstics Metal housing brass Voltage supply range 10 ... 50 VDC	Dimension: M30 x 1,5 Nominal Sensing Distance: 10...15 mm
switching frequency: < 500 Hz	Output signal:
Specific Characterstics:	PBT plastic housing
