• Housing of stainless steel 1.4404 (V4A)
• Compact and extremely robust versions
• Protection class IP 69K
• Expanded temperature ranges
• Output PNP/NPN

IFRD 06 DuroProx
	Characterstics Locked full metal housing stainless steel 1.4404 (V4A) Protection class IP 69K Expanded temperature range up to +100 °C With M8 connector	Dimension: ø 6,5 mm nominal sensing Distance: 2 mm
switching frequency:< 150 Hz	Output signal:
Specific Characterstics	M8 connector (PVC) with stainless steel cap nut as an accessory

IFRD 08 DuroProx
	Characterstics Locked full metal housing stainless steel 1.4404 (V4A) Protection class IP 69K Expanded temperature range up to +100 °C With M8 connector	Dimension: M8 x 1 nominal sensing Distance: 2 mm
switching frequency:< 150 Hz	Output signal:
Specific Characterstics	M8 connector (PVC) with stainless steel cap nut as an accessory

IFRD 12 DuroProx
	Characterstics Locked full metal housing stainless steel 1.4404 (V4A) Protection class IP 69K Expanded temperature range up to +100 °C With M12 connector	Dimension: M12 x 1 nominal sensing Distance: 4 mm
switching frequency:< 100 Hz	Output signal:
Specific Characterstics	M12 connector (PVC) with stainless steel cap nut as an accessory

IFRD 18 DuroProx
	Characterstics Locked full metal housing stainless steel 1.4404 (V4A) Protection class IP 69K Expanded temperature range up to +100 °C With M12 connector	Dimension: M18 x 1 nominal sensing Distance: 6 mm
switching frequency:< 100 Hz	Output signal:
Specific Characterstics	M12 connector (PVC) with stainless steel cap nut as an accessory
