• Robust stainless steel housing
• proTect+ sealing concept
• Protection class IP 68 / IP 69K
• EHEDG-certified
• Expanded temperature ranges
• Enhanced sensing distance

IFBR 06
	Characterstics Robust stainless steel housing IP 68 / IP 69K EHEDG-certified Ecolab-tested FDA-compliant Extended operating temperature range 40 ... +100 °C	Dimension:ø 6,5 mm Nominal sensing 3 mm Distance Resolution
switching frequency: < 3 kHz	Output signal:0...10 VDC
Specific Characterstics:	Plug connection

IFBR 11
	Characterstics Robust stainless steel housing IP 68 / IP 69K EHEDG-certified Ecolab-tested FDA-compliant Extended operating temperature range 40 ... +100 °C	Dimension:ø 11 mm Nominal sensing Distance 4 ... 6 mm Resolution
switching frequency: < 1 kHz	Output signal
Specific Characterstics:	Plug connection

IFBR 17
	Characterstics Robust stainless steel housing IP 68 / IP 69K EHEDG-certified Ecolab-tested FDA-compliant Extended operating temperature range 40 ... +100 °C	Dimension:ø 17 mm Nominal sensing Distance 8 ... 12 mm Resolution
switching frequency: < 0,5 kH	Output signal
Specific Characterstics:	Plug connection

IFRR 08
	Characterstics Robust stainless steel housing IP 68 / IP 69K EHEDG-certified Ecolab-tested FDA-compliant Extended operating temperature range 40 ... +100 °C	Dimension:M8 x 1 Nominal sensing Distance 3 mm Resolution
switching frequency: < 3 kHz	Output signal
Specific Characterstics:	Plug connection

IFRR 12
	Characterstics Robust stainless steel housing IP 68 / IP 69K EHEDG-certified Ecolab-tested FDA-compliant Extended operating temperature range 40 ... +100 °C	Dimension:M12 x 1 Nominal sensing Distance 4...6 mm Resolution
switching frequency:< 1 kHz	Output signal
Specific Characterstics:	Plug connection

IFRR 18
	Characterstics Robust stainless steel housing IP 68 / IP 69K EHEDG-certified Ecolab-tested FDA-compliant Extended operating temperature range 40 ... +100 °C	Dimension:M12 x 1 Nominal sensing Distance 4...6 mm Resolution
switching frequency:< 1 kHz	Output signal
Specific Characterstics:	Plug connection

IWRR 18 AlphaProx
	Characterstics Robust stainless steel housing IP 68 FDA-compliant Extended operating temperature range 40 ... +70 °C	Dimension:M18 x 1 Nominal sensing 0...7 mm Distance Resolution
switching frequency: 2 ms	Output signal
Specific Characterstics:	Connector version
