• Reliable detection of highly reflective and transparent objects
• Versions with two separate switching outputs.
• Sensing range up to 3000 mm
• Tolerant of dust and dirt
• Also for sensing sound-absorbing materials
• Adjustable reaction times ton/toff for through beam sensors
• Protection class IP 67
• Output PNP/NPN, Push-Pull

UNxK 09
	Characterstics Internal and external Teach-in Various mounting options Very flat housing Beam columnator for very narrow sonic cone profile IO-Link	Dimension: 8,6 x 82 x 24,5 mm sensing range Sd proximity switch 3 ... 200 mm
2 point proximity switch	retro-reflective sensors : 0 ... 200 mm
through beam sensors :	response / release time : < 7 ms
Specific Characterstics:	- With changeable beam columnator Version without beam columnator

UxDK 10 SONUS
	Characterstics Internal and external Teach-in Compact type Very low weight: 4 g Narrow sonic beam angles IO-Link	Dimension: 10,4 x 27 x 14 mm sensing range Sd proximity switch 10 ... 200 mm
2 point proximity switch	retro-reflective sensors : 0 ... 200 mm
through beam sensors :	response / release time : < 15 ms
Specific Characterstics:	- Wide range of accessories

UxDK 20
	Characterstics Internal and external Teach-in Narrow and wide sonic beam angles	Dimension: 20 x 42 x 15 mm sensing range Sd proximity switch 10 ... 1000 mm
2 point proximity switch	retro-reflective sensors : 0 ... 1000 mm
through beam sensors :	response / release time : < 10 ms
Specific Characterstics:	Small sonic beam angle Sensor with adjustable ton/toff can be mounted Sonic deflection bracket can be mounted

UxAM 12 Highspeed
	Characterstics Fastest ultrasonic sensor Lateral positioning accuracy of 0.5 mm Sonic nozzle for detection in openings of up to 3 mm External Teach-in IO-Link	Dimension: M12 x 1 sensing range Sd proximity switch 0 ... 70 mm
2 point proximity switch	retro-reflective sensors : 0 ... 70 mm
through beam sensors :	response / release time : < 1,3 ms
Specific Characterstics:	- External Teach-in adapter as an accessory - Wide range of accessories and installation options

UNAM 18 UxAR 18
	Characterstics Internal and external Teach-in Potentiometer version FDA-compliant materials Beam columnator for very narrow sonic cone profile IO-Link	Dimension: M18 x 1 sensing range Sd proximity switch 60 ... 1000 mm
2 point proximity switch	retro-reflective sensors :o ... 400 mm
through beam sensors :	response / release time : < 50 ms
Specific Characterstics:	- Sensors with stainless steel housing 1.4435 - Sensor front protected against aggressive media - Sensors with MUX and Sync input Sonic deflection bracket can be mounted

UxAM 30
	Characterstics Internal and external Teach-in Potentiometer version Increased sensing range Beam columnator for very narrow sonic cone profile IO-Link	Dimension: M30 x 15 sensing range Sd proximity switch 200 ... 1500 mm
2 point proximity switch 100 ... 1000 mm	retro-reflective sensors
through beam sensors :	response / release time : < 100 ms
Specific Characterstics:	- Sensors with MUX and Sync input

UxAM 50
	Characterstics Internal and external Teach-in Potentiometer version Large sensing range	Dimension:M30 x 15 sensing range Sd proximity switch 350 ... 2500 mm
2 point proximity switch 350 ... 2500 mm	retro-reflective sensors : 0 ... 3000 mm
through beam sensors :	response / release time : < 160 ms
Specific Characterstics:	- Sensors with MUX and Sync input
